AFD(aedis fiber duct design) is a high-tech computing environment for flexible fiber duct quotation, design, blanking, processing, installation tracking, visualization of customer relationship management and interactive programming released by Qingdao Aedis fiber Duct Co., LTD. It adopts reverse thinking to start from customer requirements (requirements of speed, temperature and humidity in working area), uses fluid equation combined with experimental correction coefficient, adopts iterative scientific calculation method of CFD, and avoids air duct shaking caused by mismatch between dynamic pressure and static pressure on the premise of meeting demand, and also avoids introducing air pipe not full due to insufficient static pressure. The application efficiency of the air volume of the fan reaches more than 95%, which represents the advanced level of the calculation software of the design system of the air distribution duct.

The main materials required for the installation of the air duct system include: air duct and its components (straight pipe, inlet, end, tee, elbow, reducer, etc.), components (PAD type duct
valves, ACD type air valves, filters, static pressure boxes, etc.) and accessories (steel ropes, lifting rings, flower basket bolts, collars, clamps, rubber sheaths, etc.) are all manufactured by the manufacturer

Provided (sent with the goods including installation drawings, installation manuals, installation and assembly drawings and other information), the remaining fixed brackets and bolts required for installation on site

Although the overall installation of the sox air duct system is simple, attention must be paid to the details during installation: the positioning size of the steel rope when installing, the verticality of the steel rope, the angle of the entrance installation, etc. Otherwise, although the ventilation effect will not be affected, it will affect the appearance of the sox system.

Smoke tests & diffuser demos

A collection of videos showing how air moves through different types of fabric ducting and diffuser options.
